5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-3 Sensor Controller Installation
5
5-3-3 FH-L Series
The power source connected to the FH-L series Sensor Controller changes the power consumption
depending on the number of camera. Refer to the following table.
When you connect the camera using lighting Controller, the power consumption is same when connect
to the Intelligent Compact Digital Camera.
Recommended Power Source for FH-L Series
Item Camera Type Number of Camera FH-L

FH-L

-

Recommended
Power Source
S8VK-G
S8VS
Intelligent Compact
Digital Camera
2 S8VK-G12024
S8VS-09024
S8VK-G112024
S8VS-09024
4
---
S8VK-G12024
S8VS-18024
Camera of
0.3/2/4/5/12 million
pixels
2 S8VK-G-06024
S8VS-06024
S8VK-G-06024
S8VS-06024
4
---
S8VK-G-06024
S8VS-06024
