4.8 Bank Function (F7/F8/F9)
4-25
HOW TO USE THE
ADVANCED FUNCTIONS
4.8.2 Switching the Active Bank
The two methods are provided for selecting the bank to be run:
selection using the bank input (terminal block) and selection using the
[BANK] key on the Cam Positioner unit.
For details, refer to the table below.
* In the default setting (this includes the status after an "all clear"
operation), the "selection using the bank input terminals (in)"
method is set.
If necessary, change the bank switching method using the F8 menu
(Refer to "4.8.6 Selecting the Bank Switching Method (F8)") in the
function setting mode.
1. Control of the start input is necessary. For details of the timing,
refer to "Appendix D Operation Timing Chart".
2. Refer to "4.8.3 Designating the Bank Using the Keys".
Description Run mode Test mode
Selection using the
bank input terminals
(in)
Designate the bank by "bank input" at the ter-
minal block.
If another bank is already set in the program-
ming mode, the designation by bank input
has priority over this setting and the desig-
nated bank is selected when the mode is
changed to test or run (when the start input
turns on).
Switchable
(*1)
Switchable
(*1)
Selection by BANK
key (key)
The bank designated in the programming
mode or test mode is selected.
All the inputs from the bank input terminals
are invalid.
Not switch-
able
Switchable
(*2)
