Omron H8PS User Manual

2.3 Mounting (Encoder)
2-15
INSTALLATION
2.3 Mounting (Encoder)
Refer to the relevant datasheet for details.
2.3.1 Dimensions and Mounting Method
■ E6CP-AG5C-C
45° 45°
38 dia.
56 dia.
50 dia.
16.9 dia.
2,000
10
50
40
37
5
3
8
1
Four, M4 holes
(depth: 10)
(*1)
(*2)
*1: Round, vinyl-insulated cord
with 10 cores (external
dia.: 6, cross-sectional
area: 0.18 mm
2
, insulation:
1.0 mm dia.), standard
length: 2 m
*2: Connector to the H8PS
Cam Positioner.
25 dia.
0
−0.2
6 dia.
−0.008
−0.020
8
16
5.5 dia. holes
Two, C1
(18) 16
9
2
(5.1)
3.1
+0.1
0
120°
120° 120°
25 dia.
Three, M5
Panel
68
±0.2
dia.
• Dimensions
• Bracket Mounting Diagram
• Accessory
Mounting Bracket (Included)
