4.2 Advance Angle Compensation (ADV) Function
4-5
HOW TO USE THE
ADVANCED FUNCTIONS
4.2.2 Specifications of Advance Angle Compensation Function
Setting
■ The Number of Advance Angle Compensation Function Setting
Enabled Outputs
The function can be set for seven outputs (cam No. 1 to 7).
(Common to all of the 8-/16-/32-output models)
The settings for each of the seven outputs can be made independently.
■ Settings (setting ranges)
When setting the ADV function, the speed and ADV value must be set.
If "---" is set for either of these settings, the ADV function is disabled for
the corresponding cam
* Even if the ADV value is set to 0°, the cam must be included in the
number of cams with ADV values set, which affects the maximum
response speed.
■ Maximum Response Speed
The maximum response speed will decrease as shown in the following
table when ADV values are set for 4 cams or more.
*1 The setting range for the ADV value is the same as that when the
number of cams with ADV values is 0 to 3.
*2 The maximum speed is 1,000 r/min when an E6CP-AG5C-C
Encoder is connected.
Encoder
Speed ADV value (*)
Resolution
Display
angle
256 256 "---", 1 to 1600 "---", 0 to 255
256 360 "---", 1 to 1600 "---", 0 to 359
360
 "---", 1 to 1600 "---", 0 to 359
720
 "---", 1 to 800 "---", 0 to 359.5
The number of
cams with ADV
settings
Encoder resolution
Max. response
speed
0 to 3
256/360 1600 r/min (*2)
720
800 r/min
4 to 7
256/360 1200 r/min (*1, *2)
720 600 r/min (*1)
