APPENDICES
A-2
APPENDICES
Appendix A Specifications (Ratings)
■ Ratings and Characteristics
● Ratings
Item
H8PS-B H8PS-BF H8PS-BP H8PS-BFP
Rated supply voltage
24 VDC
Operating voltage range
85% to 110% of rated supply voltage
Mounting method
Flush mounting Surface mounting,
track mounting
Flush mounting Surface mounting,
track mounting
Power consumption
Approx. 4.5 W at 26.4 VDC for 8-output models
Approx. 6.0 W at 26.4 VDC for 16-/32-output models
Inputs
Encoder input
Connections to a dedicated absolute encoder
External
inputs
Input
signals
8-output Models: None
16-/32-output Models: Bank inputs 1/2/4, origin input, start input
Input
type
No voltage inputs: ON impedance:1 kΩ max. (Leakage current: approx. 2 mA at 0 Ω)
ON residual voltage: 2 V max., OFF impedance: 100 kΩ min.,
Applied voltage: 30 VDC max., Minimum input signal width: 20 ms
Outputs
Cam outputs
RUN output
NPN open-collector transistor outputs
30 VDC max.,
100 mA max. (Do not exceed 1.6 A total for
all cam outputs and the RUN
output.),
residual voltage: 2 VDC max.
PNP open-collector transistor outputs
30 VDC max. (26.4 VDC for 16-/32-output
Models),
100 mA max. (Do not exceed 1.6 A total for
all cam outputs and the RUN
output.),
residual voltage: 2 VDC max.
Pulse output
NPN open-collector transistor output
30 VDC max.,
30 mA max.,
residual voltage: 0.5 VDC max.
PNP open-collector transistor output
30 VDC max. (26.4 VDC for 16-/32-output
Models)
30 mA max.,
residual voltage: 2 VDC max.
Number of
outputs
8-output Models: 8 cam outputs, 1 RUN output, 1 pulse output
16-output Models: 16 cam outputs, 1 RUN output, 1 pulse output
32-output Models: 32 cam outputs, 1 RUN output, 1 pulse output
Number of banks
8 banks (for 16-/32-output Models only)
Display method
7-segment, negative transmissive LCD (Main Display: 11 mm (red),
Sub-display: 5.5 mm (green))
Memory backup method
EEPROM (overwrites: 100000 times min.) that can store data for 10 years min.
Ambient operating
temperature
− 10 to 55°C (with no icing or condensation)
Storage temperature
− 25 to 65°C (with no icing or condensation)
Ambient humidity
25% to 85%
Degree of protection
Panel surface: IP40, Rear case: IP20
Case color
Light gray (Munsell 5Y7/1)
Electromagnetic
environment
Industrial electromagnetic (EN/IEC 61326-1 Table 2)
