Omron H8PS User Manual

Section 2 INSTALLATION
2-2
INSTALLATION
2.1 Designing the System
2.1.1 Selecting the Encoder
The three series (eight models) of dedicated absolute encoder products shown below are available.
Choose the most appropriate model for your application.
Note that the encoders can be used with all the H8PS-series Cam Positioners.
Refer to the relevant datasheet for details.
■ Dedicated Absolute Encoder
Type Description Resolution
Cable
length
Model
Economy Low-cost products 256 2 m E6CP-AG5C-C 256P/R 2M
Standard Standard products that can
be used in environments
where the encoder is directly
exposed to water or oil
256 1 m E6C3-AG5C-C 256P/R 1M
2 m E6C3-AG5C-C 256P/R 2M
360 E6C3-AG5C-C 360P/R 2M
720 E6C3-AG5C-C 720P/R 2M
Rigid Ruggedly constructed prod-
ucts with high allowable
shaft load tolerance that can
be used in environments
where the encoder is directly
exposed to water or oil
256 2 m E6F-AG5C-C 256P/R 2M
360 E6F-AG5C-C 360P/R 2M
720 E6F-AG5C-C 720P/R 2M
