Operatio
n Timing Char
t
A-15
APPENDICES
■
Output Response Time
<Example> ON angle: 28
°
,
OFF angle: 51
°
(The response
time is not influe
nced by the
set angles
.)
■
At P
ower ON/OFF
27
28
29
50
51 52
ON
OFF
ON
OFF
TT
TT
T: 0.3 ms max.
Cam output
(in CW rotation)
(in CCW rotation)
T2
T3
ON
OFF
Input status
T1:
1.3 s max. (in normal operation)
3.5 s max. (when the resolution is changed with the DIP switch)
T2:
5 ms max.
T3:
1 s max.
Power Supply
Unstable
Unstable
Accepted
Not accepted
128
