Caution Do not touch the Servo Driver radiator, regeneration resistors or Servomotor while
the power is being supplied or soon after the power is turned OFF. Doing so may
result in a burn injury due to the hot surface.
Storage and Transportation Precautions
Caution Do not hold the product by the cables or motor shaft while transporting it. Doing so
may result in injury or malfunction.
Caution Do not place any load exceeding the figure indicated on the product. Doing so may
result in injury or malfunction.
Caution Use the motor eye-bolts only for transporting the Motor. Using them for transporting
the machinery may result in injury or malfunction.
Installation and Wiring Precautions
Caution Do not step on or place a heavy object on the product. Doing so may result in injury.
Caution Do not cover the inlet or outlet ports and prevent any foreign objects from entering
the product. Doing so may result in fire.
Caution Be sure to install the product in the correct direction. Not doing so may result in mal-
function.
Caution Provide the specified clearances between the Servo Driver and the control panel or
with other devices. Not doing so may result in fire or malfunction.
Caution Do not apply any strong impact. Doing so may result in malfunction.
Caution Be sure to wire correctly and securely. Not doing so may result in motor runaway,
injury, or malfunction.
Caution Be sure that all the mounting screws, terminal screws, and cable connector screws
are tightened to the torque specified in the relevant manuals. Incorrect tightening
torque may result in malfunction.
Caution Use crimp terminals for wiring. Do not connect bare stranded wires directly to termi-
nals. Connection of bare stranded wires may result in burning.
Caution Always use the power supply voltage specified in the User’s Manual. An incorrect
voltage may result in malfunction or burning.
To Next Page
