4-11

4-12. Outdoor Units Control PCB

4-12-1. Single-Phase Unit

CR-PCB

A746894 (U-60PE1R5, U-71PE1R5)

A.ADD

MODE

D303

(LED2)

D302

(LED1)

S003

JP001

TERMINAL

S002

CN-OPT1

CN-OPT2

EMG plug

(CN-EMG)

SILENT

(CN-

SILENT)

TEST

RUN

STOP

LED for

EEPROM

memory

(D330)

POWER LED

(D514)

Outdoor air

temp

(CN-TO)

Comp

discharge

temp

(CN-TD)

RC plug

(CN-RC)

PUMP

DOWN

Suction

temp

(CN-TS)

High-pressure

switch plug

(CN-63PH)

OC plug

(CN-OC)

MOV plug

(CN-MOV1)

EEPROM memory IC

(IC18)

CHK

Intermediate

temperature

sensor in heat

exchanger

(CN-C2)

Inlet

temperature

sensor in heat

exchanger

(CN-C1)

䡵
