1-1. Unit Speciﬁ cations

Ducted Type S-71PE1R5 / U-71PE1R5

INDOOR MODEL S–71PE1R5

PANEL MODEL –

OUTDOOR MODEL U–71PE1R5

Branch pipe MODEL –

PERFORMANCE TEST CONDITION ISO5151 / AS/NZS3823

POWER SUPPLY

ø, Hz 1ø 50 Hz 1ø 50 Hz

V 230 V 240 V 230 V 240 V Min Max

CAPACITY

kW 7.1 7.1 2.5 8.0

BTU/h 24200 24200 8500 27300

CURRENT A 1.24 1.25 9.1 8.80 – –

INPUT POWER

W 275 290 1.925 k 1.910 k – –

TOTAL W – 2.200 k 2.200 k 685 2.855 k

ANNUAL CONSUMPTION TOTAL W *

–1100–––

EER/AEER /STR RAT TOTAL (W/W) – –

3.23/3.16/–

3.23 3.65 2.80

Erp *

Pdsign kW ––––––

SEER (W/W) ––––––

Class ––––––

POWER FACTOR % – – 92 90 – –

NOISE INDOOR

(H/L)

dB–A 45/43

Power Level dB 62/60

NOISE OUTDOOR

(H/L)

dB–A 48/–

Power Level dB 65/–

CAPACITY

kW 8.0 8.0 2.0 9.0

BTU/h 27300 27300 6800 30700

CURRENT A 1.24 1.25 9.3 9.0 – –

INPUT POWER

W 275 290 2.025 k 2.010 k – –

TOTAL W – 2.300 k 2.300 k 635 3.135 k

COP/ACOP /STR RAT TOTAL (W/W) – –

3.48/3.41/–

3.48 3.15 2.87

Erp *

Pdsign kW ––––––

Tbivalen ˚C ––––––

SCOP (W/W) ––––––

Annual consumption kWh ––––––

Class ––––––

POWER FACTOR % – – 95 93 – –

NOISE INDOOR

(H/L)

dB–A 45/43 – / /

Power Level dB 62/60 –

NOISE OUTDOOR

(H/L)

dB–A – 50/– / /

Power Level dB – 67/–

EXTRA LOW TEMP

TOTAL CAPACITY(kW)/INPUT POWER(W)/COP

–

MAX CURRENT(A)/MAX INPUT POWER(W)

1.30/0.290 k 1.31/0.305 k 18.0/3.93 k 18.0/4.060 k

STARTING CURRENT(A)/COMP OUTPUT(W) – –

9.3/2.0 K 9.0/2.0 K

NETWORK IMPEDANCE(ΩMAX.) – –

FM OUTPUT (W) 155 90 /

MOISTURE REMOVAL VOLUME L/h(Pt/h) 4.2 (8.8) –

Extarnal static pressure

Pa (mmAq)

100 (MIN10 – MAX150)

I/D AIR

FLOW

COOL m

/min (ft

/min) 30 (1059)

HEAT m

/min (ft

/min) 30 (1059)

O/D AIR

FLOW

COOL m

/min (ft

/min) 60 (2119)

HEAT m

/min (ft

/min) 60 (2119)

REFRIGERANT TYPE, AMOUNT g(oz) R410A 2.35 k (82.9) /

HEIGHT

H mm (inch) 360 (14–5/32) 996 (39–7/32) /

WIDTH

W mm (inch)

1100(+100)

(

43–5/16(+3–15/16))

940 (37–1/32) /

DEPTH

D mm (inch) 700 (27–9/16) 340 (13–13/32) /

HEIGHT

H mm 445 1136 /

WIDTH

W mm 1315 1055 /

DEPTH

D mm 812 485 /

MASS

(NET) kg(lb) 42 69 /

(GROSS) kg(lb) 50 77 /

LAYERS LIMIT (actually) 6(7) 2(3)

Operation

Condition

Cool (DBT) 18˚C – 32˚C -15˚C – 46˚C

Heat (DBT) 16˚C – 30˚C -20˚C – 24˚C

PIPE DIAMETER mm (inch)

(Liquid)

9.52(3/8) (Gas)

15.88(5/8) (Liquid)

9.52(3/8) (Gas)

15.88(5/8)

CONNECT METHOD, STD LENGTH m (ft) ﬂ ared type, 5.0(16.4) ﬂ ared type, 5.0(16.4)

PIPE LENGTH RANGE m (ft) 5 – 50 (16.4 – 164.0) – –

I/D&O/D HEIGHT DIRRERENCE m (ft) 15 (OD located lower)/30 (OD located higher) (49.2/98.4)

ADD GAS AMOUNT g/m (oz/ft) 50 (537.6)

PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)

:

In case it is necessary to indicate the air ﬂ ow volume in (l/s), the value in (m

/min.) shall be multiplied by 16.7 and rounded down the decimal point.

:

If the EUROVENT Certiﬁ ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet–bulb temperatures with rated voltage

230 V shall be used.

:

Network Impedance shall be applicable for EUROPE and CHINA models.

:

The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.

:

EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.

:

SEER and SCOP classification is at 230V (400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,

Other fiche data indicates in an attached sheet.
