1-13

Single-Type

1-1. Unit Speciﬁ cations

Single Split Type S-125PU1R5 / U-125PE1R8

INDOOR MODEL S–125PU1R5

PANEL MODEL CZ-KPU2

OUTDOOR MODEL U–125PE1R8

Branch pipe MODEL –

PERFORMANCE TEST CONDITION AS/NZS3823.1

POWER SUPPLY

ø, Hz 1ø 50 Hz 3ø 50 Hz

V 230 V 240 V 400 V 415 V Min Max

CAPACITY

kW 12.5 12.5 3.3 14.0

BTU/h 42700 42700 11300 47800

CURRENT A 0.76 0.73 5.15 5.00 – –

INPUT POWER

W 100 100 3.370 k 3.370 k – –

TOTAL W – 3.470 k 3.470 k 840 4.600 k

ANNUAL CONSUMPTION TOTAL W *

– 1735 – – –

EER/AEER /STR RAT TOTAL (W/W) – –

3.60/3.56/–

3.60 3.93 3.04

Erp *

Pdsign kW ––––––

SEER (W/W) ––––––

Class ––––––

POWER FACTOR % – – 94 94 – –

NOISE INDOOR

(H/L)

dB–A 45/33

Power Level dB 63/50

NOISE OUTDOOR

(H/L)

dB–A 53/–

Power Level dB 70/–

CAPACITY

kW 14.0 14.0 4.1 16.0

BTU/h 47800 47800 14000 54600

CURRENT A 0.73 0.73 5.20 5.05 – –

INPUT POWER

W 100 100 3.400 k 3.400 k – –

TOTAL W – 3.500 k 3.500 k 900 5.200 k

COP/ACOP /STR RAT TOTAL (W/W) – –

4.00/3.95/–

4.00 4.56 3.08

Erp *

Pdsign kW ––––––

Tbivalen ˚C ––––––

SCOP (W/W) ––––––

Annual consumption kWh ––––––

Class ––––––

POWER FACTOR % – – 94 94 – –

NOISE INDOOR

(H/L)

dB–A 45/33 – / /

Power Level dB 63/50 –

NOISE OUTDOOR

(H/L)

dB–A – 53/– / /

Power Level dB – 70/–

EXTRA LOW TEMP

TOTAL CAPACITY(kW)/INPUT POWER(W)/COP

–

MAX CURRENT(A)/MAX INPUT POWER(W)

0.76/100 k 0.73/100 k

10.0/6.500 k 10.0/6.750 k

STARTING CURRENT(A)/COMP OUTPUT(W) – –

5.20/3.0 K 5.05/3.0 K

NETWORK IMPEDANCE(ΩMAX.) – –

FM OUTPUT (W) 90 90 × 2 /

MOISTURE REMOVAL VOLUME L/h(Pt/h) 6.0 (12.6) –

Extarnal static pressure

Pa (mmAq)

–

I/D AIR

FLOW

COOL m

/min (ft

/min) 35 (1236)

HEAT m

/min (ft

/min) 35 (1236)

O/D AIR

FLOW

COOL m

/min (ft

/min) 130 (4591)

HEAT m

/min (ft

/min) 110 (3885)

REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40 k (119.9) /

HEIGHT

H mm (inch) 319 (12–9/16) 1416 (55–3/4) /

WIDTH

W mm (inch) 840 (33–3/32) 940 (37–1/32) /

DEPTH

D mm (inch) 840 (33–3/32) 340 (13–13/32) /

HEIGHT

H mm 361 1556 /

WIDTH

W mm 929 1055 /

DEPTH

D mm 929 485 /

MASS

(NET) kg(lb) 27 98 /

(GROSS) kg(lb) 34 108 /

LAYERS LIMIT (actually) 11(12) 1(2)

Operation

Condition

Cool (DBT) 18˚C – 32˚C -15˚C – 46˚C

Heat (DBT) 16˚C – 30˚C -20˚C – 24˚C

PIPE DIAMETER mm (inch)

(Liquid)

9.52(3/8) (Gas)

15.88(5/8) (Liquid)

9.52(3/8) (Gas)

15.88(5/8)

CONNECT METHOD, STD LENGTH m (ft) ﬂ ared type, 5.0(16.4) ﬂ ared type, 5.0(16.4)

PIPE LENGTH RANGE m (ft) 5 – 75 (16.4 – 246.1) – –

I/D&O/D HEIGHT DIRRERENCE m (ft) 15 (OD located lower)/30 (OD located higher) (49.2/98.4)

ADD GAS AMOUNT g/m (oz/ft) 50 (537.6)

PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)

:

In case it is necessary to indicate the air ﬂ ow volume in (l/s), the value in (m

/min.) shall be multiplied by 16.7 and rounded down the decimal point.

:

If the EUROVENT Certiﬁ ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet–bulb temperatures with rated voltage

230 V shall be used.

:

Network Impedance shall be applicable for EUROPE and CHINA models.

:

The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.

:

EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.

:

SEER and SCOP classification is at 230V (400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,

Other fiche data indicates in an attached sheet.
