1-1. Unit Speciﬁ cations

Ducted Type S-125PE1R5 / U-125PE1R5

INDOOR MODEL S–125PE1R5

PANEL MODEL –

OUTDOOR MODEL U–125PE1R5

Branch pipe MODEL –

PERFORMANCE TEST CONDITION ISO5151 / AS/NZS3823

POWER SUPPLY

ø, Hz 1ø 50 Hz 1ø 50 Hz

V 230 V 240 V 230 V 240 V Min Max

CAPACITY

kW 12.5 12.5 3.3 14.0

BTU/h 42700 42700 11300 47800

CURRENT A 1.82 1.84 16.0 15.4 – –

INPUT POWER

W 410 430 3.490 k 3.470 k – –

TOTAL W – 3.900 k 3.900 k 1000 4.800 k

ANNUAL CONSUMPTION TOTAL W *

– 1950 – – –

EER/AEER /STR RAT TOTAL (W/W) – –

3.21/3.17/–

3.21 3.30 2.92

Erp *

Pdsign kW ––––––

SEER (W/W) ––––––

Class ––––––

POWER FACTOR % – – 95 94 – –

NOISE INDOOR

(H/L)

dB–A 49/45

Power Level dB 71/67

NOISE OUTDOOR

(H/L)

dB–A 53/–

Power Level dB 70/–

CAPACITY

kW 14.0 14.0 4.1 16.0

BTU/h 47800 47800 14000 54600

CURRENT A 1.82 1.84 17.2 16.6 – –

INPUT POWER

W 410 430 3.750 k 3.730 k – –

TOTAL W – 4.160 k 4.160 k 1050 5.400 k

COP/ACOP /STR RAT TOTAL (W/W) – –

3.37/3.33/–

3.37 3.90 2.96

Erp *

Pdsign kW ––––––

Tbivalen ˚C ––––––

SCOP (W/W) ––––––

Annual consumption kWh ––––––

Class ––––––

POWER FACTOR % – – 95 94 – –

NOISE INDOOR

(H/L)

dB–A 49/45 – / /

Power Level dB 71/67 –

NOISE OUTDOOR

(H/L)

dB–A – 53/– / /

Power Level dB – 70/–

EXTRA LOW TEMP

TOTAL CAPACITY(kW)/INPUT POWER(W)/COP

–

MAX CURRENT(A)/MAX INPUT POWER(W) 2.1/0.47 k 2.2/0.50 k

28.0/6.200 k 28.0/6.400 k

STARTING CURRENT(A)/COMP OUTPUT(W) – –

15.7/3.0 K 15.2/3.0 K

NETWORK IMPEDANCE(ΩMAX.) – –

FM OUTPUT (W) 310 90 × 2 /

MOISTURE REMOVAL VOLUME L/h(Pt/h) 7.9 (16.6) –

Extarnal static pressure

Pa (mmAq)

100 (MIN10 – MAX150)

I/D AIR

FLOW

COOL m

/min (ft

/min) 50 (1766)

HEAT m

/min (ft

/min) 50 (1766)

O/D AIR

FLOW

COOL m

/min (ft

/min) 130 (4591)

HEAT m

/min (ft

/min) 110 (3885)

REFRIGERANT TYPE, AMOUNT g(oz) R410A 3.40 k (119.9) /

HEIGHT

H mm (inch) 430 (16–15/16) 1416 (55–3/4) /

WIDTH

W mm (inch)

1100(+100)

(

43–5/16(+3–15/16))

940 (37–1/32) /

DEPTH

D mm (inch) 700 (27–9/16) 340 (13–13/32) /

HEIGHT

H mm 515 1556 /

WIDTH

W mm 1315 1055 /

DEPTH

D mm 812 485 /

MASS

(NET) kg(lb) 48 98 /

(GROSS) kg(lb) 56 108 /

LAYERS LIMIT (actually) 6(7) 1(2)

Operation

Condition

Cool (DBT) 18˚C – 32˚C -15˚C – 46˚C

Heat (DBT) 16˚C – 30˚C -20˚C – 24˚C

PIPE DIAMETER mm (inch)

(Liquid)

9.52(3/8) (Gas)

15.88(5/8) (Liquid)

9.52(3/8) (Gas)

15.88(5/8)

CONNECT METHOD, STD LENGTH m (ft) ﬂ ared type, 5.0(16.4) ﬂ ared type, 5.0(16.4)

PIPE LENGTH RANGE m (ft) 5 – 75 (16.4 – 246.1) – –

I/D&O/D HEIGHT DIRRERENCE m (ft) 15 (OD located lower)/30 (OD located higher) (49.2/98.4)

ADD GAS AMOUNT g/m (oz/ft) 50 (537.6)

PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)

*1: In case it is necessary to indicate the air ﬂ ow volume in (l/s), the value in (m

/min.) shall be multiplie d by 16.7 and rounded down the decimal point.

:

If the EUROVENT Certiﬁ ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet–bulb temperatures with rated voltage

230 V shall be used.

:

Network Impedance shall be applicable for EUROPE and CHINA models.

:

The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.

:

EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.

:

SEER and SCOP classification is at 230V (400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,

Other fiche data indicates in an attached sheet.
