1-1. Unit Speciﬁ cations

Ducted Type S-60PE1R5 / U-60PE1R5

INDOOR MODEL S–60PE1R5

PANEL MODEL –

OUTDOOR MODEL U–60PE1R5

Branch pipe MODEL –

PERFORMANCE TEST CONDITION ISO5151 / AS/NZS3823

POWER SUPPLY

ø, Hz 1ø 50 Hz 1ø 50 Hz

V 230 V 240 V 230 V 240 V Min Max

CAPACITY

kW 6.0 6.0 2.5 7.1

BTU/h 20500 20500 8500 24200

CURRENT A 0.85 0.86 7.85 7.65 – –

INPUT POWER

W 190 200 1.660 k 1.650 k – –

TOTAL W – 1.850 k 1.850 k 605 2.155 k

ANNUAL CONSUMPTION TOTAL W *

– 925 – – –

EER/AEER /STR RAT TOTAL (W/W) – –

3.24/3.17/–

3.24 4.13 3.29

Erp *

Pdsign kW ––––––

SEER (W/W) ––––––

Class ––––––

POWER FACTOR % – – 92 90 – –

NOISE INDOOR

(H/L)

dB–A 43/40

Power Level dB 60/57

NOISE OUTDOOR

(H/L)

dB–A 48/–

Power Level dB 65/–

CAPACITY

kW 7.0 7.0 2.0 8.0

BTU/h 23900 23900 6800 27300

CURRENT A 0.85 0.86 8.8 8.6 – –

INPUT POWER

W 190 200 1.860 k 1.850 k – –

TOTAL W – 2.050 k 2.050 k 555 2.635 k

COP/ACOP /STR RAT TOTAL (W/W) – –

3.41/3.34/–

3.41 3.60 3.04

Erp *

Pdsign kW – –––––

Tbivalen ˚C ––––––

SCOP (W/W) ––––––

Annual consumption kWh ––––––

Class ––––––

POWER FACTOR % – – 92 90 – –

NOISE INDOOR

(H/L)

dB–A 43/40 – / /

Power Level dB 60/57 –

NOISE OUTDOOR

(H/L)

dB–A – 50/– / /

Power Level dB – 67/–

EXTRA LOW TEMP

TOTAL CAPACITY(kW)/INPUT POWER(W)/COP

–

MAX CURRENT(A)/MAX INPUT POWER(W)

0.89/0.200 k 0.90/0.210 k 18.0/3.93 k 18.0/4.060 k

STARTING CURRENT(A)/COMP OUTPUT(W) – –

8.8/1.7 K 8.6/1.7 K

NETWORK IMPEDANCE(ΩMAX.) – –

FM OUTPUT (W) 90 90 /

MOISTURE REMOVAL VOLUME L/h(Pt/h) 3.4 (7.1) –

Extarnal static pressure

Pa (mmAq)

70 (MIN10 – MAX100)

I/D AIR

FLOW

COOL m

/min (ft

/min) 22 (777)

HEAT m

/min (ft

/min) 22 (777)

O/D AIR

FLOW

COOL m

/min (ft

/min) 60 (2119)

HEAT m

/min (ft

/min) 60 (2119)

REFRIGERANT TYPE, AMOUNT g(oz) R410A 2.00 k (70.5) /

HEIGHT

H mm (inch) 290 (11–13/32) 996 (39–7/32) /

WIDTH

W mm (inch)

1100(+100)

(

43–5/16(+3–15/16))

940 (37–1/32) /

DEPTH

D mm (inch) 700 (27–9/16) 340 (13–13/32) /

HEIGHT

H mm 375 1136 /

WIDTH

W mm 1315 1055 /

DEPTH

D mm 812 485 /

MASS

(NET) kg(lb) 35 68 /

(GROSS) kg(lb) 42 76 /

LAYERS LIMIT (actually) 6(7) 2(3)

Operation

Condition

Cool (DBT) 18˚C – 32˚C -15˚C – 46˚C

Heat (DBT) 16˚C – 30˚C -20˚C – 24˚C

PIPE DIAMETER mm (inch)

(Liquid)

9.52(3/8) (Gas)

15.88(5/8) (Liquid)

9.52(3/8) (Gas)

15.88(5/8)

CONNECT METHOD, STD LENGTH m (ft) ﬂ ared type, 5.0(16.4) ﬂ ared type, 5.0(16.4)

PIPE LENGTH RANGE m (ft) 5 – 50 (16.4 – 164.0) – –

I/D&O/D HEIGHT DIRRERENCE m (ft) 15 (OD located lower)/30 (OD located higher) (49.2/98.4)

ADD GAS AMOUNT g/m (oz/ft) 50 (537.6)

PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)

:

In case it is necessary to indicate the air ﬂ ow volume in (l/s), the value in (m

/min.) shall be multiplied by 16.7 and rounded down the decimal point.

:

If the EUROVENT Certiﬁ ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet–bulb temperatures with rated voltage

230 V shall be used.

:

Network Impedance shall be applicable for EUROPE and CHINA models.

:

The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.

:

EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.

:

SEER and SCOP classification is at 230V (400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,

Other fiche data indicates in an attached sheet.
