1-8. Airflow Distance Chart
4-Way Cassette Type
0
1
2
3
0
1
2
3
1.5m/s
1.0m/s
0.5m/s
0.3m/s
Vertical air flow distance (m)
Horizontal air flow distance (m)
54321012345
(Strong wind : Discharge angle approx.65°) (Room temperature approx.20°C)
0
1
2
3
0
1
2
3
1.5m/s
1.0m/s
0.5m/s
0.3m/s
Vertical air flow distance (m)
Horizontal air flow distance (m)
54321012345
(Strong wind : Discharge angle approx.30°) (Room temperature approx.27°C)
0
1
2
3
0
1
2
3
20
24
26
22
Vertical air flow distance (m)
Horizontal air flow distance (m)
54321012345
(Strong wind : Discharge angle approx.30°) (Room temperature approx.27°C)
0
1
2
3
0
1
2
3
33
27
24
30
Vertical air flow distance (m)
Horizontal air flow distance (m)
54321012345
(Strong wind : Discharge angle approx.65°) (Room temperature approx.20°C)
S-60PU1R5 / 71PU1R5
Heating : Distribution of wind velocity
Heating : Distribution of temperature
Cooling : Distribution of wind velocity
Cooling : Distribution of temperature
