Technical Data
16 Rev. G Nov/2015 MI3
3.1.2 Comm Box
Accuracy
mA/V output ± 1°C
(corresponds to ± 0.015 mA for the current output at 0-20 mA
or ± 0.015 mA for the current output at 4-20 mA
or 4 mV for the voltage output at 0-5 V
or 8 mV for the voltage output at 0-10 V)
TC output ± 1.5°C
Temperature Resolution
mA/V Output ± 0.1°C (± 0.2°F)
1
/ 12 bit, for Comm Box (metal)
mA/V Output ± 0.02°C (± 0.04°F) / 16 bit, for Comm Box (DIN 6TE, analog)
Temperature Coefficient
mA/V Output ± 0.02 K / K
TC Output ± 0.05 K / K
Emissivity
All models 0.100 to 1.100
Transmission
All models 0.100 to 1.000
3.1.2.1 Comm Box (metal)
Loop Time
mA/V Output
LTS, G5 8 ms
LTF, 1M, 2M 4 ms
digital 18 ms * number of connected heads
3.1.2.2 Comm Box (DIN)
Loop Time
digital
LTS, G5 8 ms
2
* number of connected heads
LTF, 1M, 2M 4 ms
3
* number of connected heads
1
for a zoomed temperature span of < 500°C (932°F)
2
per bus channel
3
per bus channel
