MI3 Rev. G Nov/2015 67

10.1.2 USB/RS485 Adapter

The USB/RS485 adapter is self-powering via the USB connection.

Figure 51: USB/RS485 Adapter (XXXUSB485)

Figure 52: Wiring the RS485 Interface of the Box (left)

and USB/RS485 Adapter (right)

Termination
