Outputs
40 Rev. G Nov/2015 MI3
6 Outputs
For the outputs the following groupings (setups) are possible:
Output
Setup 1
Setup 2
Setup 3
Setup 4
Setup 5
OUT1
head temperature
V
head temperature
V
object temperature
V
object temperature
V

OUT2
object temperature
mA
object temperature
V
object temperature
mA
object temperature
V
head temperature
V
TC




object temperature
6.1 Analog Output OUT1
Comm Box:
metal
Source:
object temperature / head ambient temperature
Signal:
0 to 5/10 V
Terminal:
OUT1, GND
This output can be configured for the object or the head ambient temperature. E.g. the output range
for the head ambient temperature is 0 to 5 VDC corresponding to 0 to 500°C (32 to 932°F). The
minimum load impedance for the voltage output must be 10 kΩ.
The output is short circuit resistant.
6.2 Analog Output OUT2
Comm Box:
metal
Source:
object temperature / head ambient temperature
Signal:
0/4 to 20 mA or 0 to 5/10 V
Terminal:
OUT2, GND
The signal output can be configured as either current or voltage output. The minimum load
impedance for the voltage output must be 10 kΩ. The maximum current loop impedance for the mA
output is 500 Ω.
The output is short circuit resistant.
The outputs <OUT1> and <TC> are not available at the same time!
