Installation
MI3 Rev. G Nov/2015 31
5.4.3 Comm Box (DIN 4 TE)
Figure 16: Terminal Wiring for the Comm Box DIN 4 TE
RELAY
Sensing Heads
GND
FTC3
8 - 32 V
Shield
A (RS485)
B (RS485)
GND
RELAY
shield
green
white
yellow
brown
Termination
shield
green
white
yellow
brown
USB Connector, Mini-B
