Accessories
64 Rev. G Nov/2015 MI3
10 Accessories
A full range of accessories for various applications and industrial environments are available.
Accessories include items that may be ordered at any time and added on-site.
10.1 Accessories (all models)
Multi-Channel Box (XXXMI3CONNBOX)
USB/RS485 Adapter for boxes with RS485 interface (XXXUSB485)
10.1.1 Multi-Channel Box
The Multi-Channel Box can be used for all communication boxes. The box includes 8 sets of field
wiring terminals wired in parallel to one 5 m (16 ft) cable set to connect to the communication box.
Figure 47: Multiple Head Configuration with Comm Box
Technical Data
Ambient Temperature -20 to 100°C (-4 to 212°F)
Storage Temperature -20 to 100°C (-4 to 212°F)
Rating IP65 (NEMA-4) / IEC 60529
Relative Humidity 10% to 95% non-condensing
Vibration 11 to 200 Hz, 3 g above 25 Hz operating, 3 axes / IEC 60068-2-6
Shock 50 g, 11 ms, operating, 3 axes / IEC 60068-2-27
The Multi-Channel Box must not be used with Ex power supply IS unit for wiring
heads.
