Installation
32 Rev. G Nov/2015 MI3
5.4.4 Comm Box (DIN 6 TE)
Figure 17: Terminal Wiring for the Comm Box DIN 6 TE
for Profibus and Modbus
Wiring Profibus or Modbus
RELAY
Sensing
Heads
GND
FTC3
8 - 32 V
Shield
GND
RELAY
shield
green
white
yellow
brown
shield
green
white
yellow
brown
USB Connector, Mini-B
