Machine Overview
Component Layout
1. Laser Optics Housing Unit
2. Print Cartridge (AIO)
3. Paper Exit
4. Inverter Path
5. Fusing Belt
6. Pressure Roller
7. Fusing Lamp
8. ITB (Image Transfer Belt) Unit
9. By-pass Tray
10. Transfer Roller
11. Registration Roller
12. By-pass Feed Roller
13. Paper Feed Roller
14. Tray 1
15. OPC (AIO)
16. Waste Toner Bottle
17. EGB/ Controller Board
