4. Pull out the by-pass feed roller shaft [B] (bushing x 1).
5.
Pick-up roller [C]
When installing the by-pass pick-up and feed rollers
Make sure that the small plastic bushing [A] is correctly inserted between the pick-up or feed roller [B]
and roller support plate [C].
Paper End Sensor
1. Rear cover ( p.25)
2.
Right cover (
p.27)
Paper Feed and Exit
71
4
