After installing a new image transfer belt unit
Execute SP2-120-009 (Transfer Belt Adj) after installing a new image transfer belt unit.
Agitator Motor
1. Right cover ( p.27)
2. Motor bracket [A] ( x 2)
3. Agitator motor assembly [B] ( x 1, x 1)
4. Replacement and Adjustment
42
4
