Paper Feed and Exit
Paper Feed Clutch
1. Rear cover ( p.25)
2.
Left cover (
p.27)
3. Paper feed clutch [A] ( x 1, x 1)
Paper Feed Roller
1. Pull out the tray.
2.
Open the front cover.
3. Transfer unit (
p.50)
4.
Paper feed clutch (
p.66)
4. Replacement and Adjustment
66
4
