Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-166 DS2000E Programming Guide
:MEASure:PDUTy
Syntax 1
:MEASure:PDUTy <chan>
Description 1
Enable the positive duty cycle measurement function of the specified channel.
Syntax 2
:MEASure:PDUTy? <chan>
Description 2
Enable the positive duty cycle measurement function of the specified channel and return the
measurement result.
Parameter
Name Type Range Default
<chan> Discrete {CHANnel1|CHANnel2|MATH} --
Return Format
The query returns the positive duty cycle measurement result in scientific notation. When the
measurement result is invalid, the query returns 9.9e37.
Example
:MEASure:PDUTy CHANnel1
:MEASure:PDUTy? CHANnel1
You can use the following commands to enable the positive duty cycle measurement function of the
specified channel and the statistic function of the measurement results as well as query the statistic
maximum value, minimum value, current value, average value, and standard deviation of the positive
duty cycle measurement results.
 :MEASure:PDUTy:SMAXimum
 :MEASure:PDUTy:SMINimum
 :MEASure:PDUTy:SCURrent
 :MEASure:PDUTy:SAVerage
 :MEASure:PDUTy:SDEViation

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
