Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-243
:TIMebase:MODE
Syntax
:TIMebase:MODE <mode>
:TIMebase:MODE?
Description
Set or query the horizontal time base mode.
Parameter
Name Type Range Default
<mode> Discrete {MAIN|XY|ROLL} MAIN
Explanation
 MAIN: Y-T mode
 XY: X-Y mode
 ROLL: Roll mode
Return Format
The query returns MAIN, XY, or ROLL.
:TIMebase:VERNier
Syntax
:TIMebase:VERNier <bool>
:TIMebase:VERNier?
Description
Enable or disable the fine adjustment of the horizontal scale; or query the current status of the fine
adjustment of the horizontal scale.
Parameter
Name Type Range Default
<bool> Bool {{1|ON}|{0|OFF}} 0|OFF
Return Format
The query returns 1 or 0.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
