Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-23
:BUS<n>:RS232 (Option)
 :BUS<n>:RS232:TX
 :BUS<n>:RS232:RX
 :BUS<n>:RS232:POLarity
 :BUS<n>:RS232:ENDian
 :BUS<n>:RS232:BAUD
 :BUS<n>:RS232:BUSer
 :BUS<n>:RS232:DBITs
 :BUS<n>:RS232:SBITs
 :BUS<n>:RS232:PARity
 :BUS<n>:RS232:PACKet
 :BUS<n>:RS232:PEND
 :BUS<n>:RS232:TTHReshold
 :BUS<n>:RS232:RTHReshold
 :BUS<n>:RS232:OFFSet
:BUS<n>:RS232:TX
Syntax
:BUS<n>:RS232:TX <source>
:BUS<n>:RS232:TX?
Description
Set or query the TX channel source of RS232 decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<source> Discrete {CHANnel1|CHANnel2|OFF} CHANnel1
Explanation
When OFF is selected, no TX channel source will be set. The TX channel source and RX channel source
cannot both be set to OFF.
Return Format
The query returns CHAN1, CHAN2, or OFF.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
