RIGOL 2 Command System
2-270 DS2000E Programming Guide
:TRIGger:NEDGe:LEVel
Syntax
:TRIGger:NEDGe:LEVel <level>
:TRIGger:NEDGe:LEVel?
Description
Set or query the trigger level of Nth edge trigger when the trigger source is CHANnel1 or CHANnel2. The
unit is the same with the current amplitude unit.
Parameter
Name Type Range Default
<level> Real -5×VerticalScale–OFFSet to +5×VerticalScale–OFFSet 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Explanation
To set the trigger source of Nth edge trigger, please refer to the
:TRIGger:NEDGe:SOURce command.
Return Format
The query returns the trigger level of Nth edge trigger when the trigger source is CHANnel1 or CHANnel2
in scientific notation.
:TRIGger:NEDGe:SLOPe
Syntax
:TRIGger:NEDGe:SLOPe <slope>
:TRIGger:NEDGe:SLOPe?
Description
Set or query the edge type of Nth edge trigger.
Parameter
Name Type Range Default
<slope> Discrete {POSitive|NEGative} POSitive
Return Format
The query returns POSitive or NEGative.
