Device structure
MOVIMOT® flexible MMF1.
Operating Instructions – MOVIMOT
®
flexible
14
3 Device structure
3.1 MOVIMOT
®
flexible MMF1.
MOVIMOT®
flexible
MMF1.
MOVIMOT
®
flexible MMF1. is a decentralized frequency inverter that serves to control
drive units. It comprises of 2 core components, the electronics cover and the universal
connection box (see the following figure).
7
6646 Bru
c
h
s
al/Ge
rma
n
y
MMF11S00-
000-SF
CDI0-
C
/DSP/IV/DFC20A-0020
01.1234567890.0001.14
LISTE
D I
ND.
CONT.E
Q
.2D06
®
Eing
ang
/In
p
u
t
U =AC
3
x38
0
...500
V
I =
AC 1.9A
f =50...60Hz
T =-25
°
C...+40°C IP 54 ML
000
1
28108558
U =
3
x0...U
inp
u
t
I =AC
2
.0A
f =
0...59
9
H
z
Ausg
a
ng/Output
5 m
i
n
[5]
[6]
[7]
[8]
[2]
[3]
[4]
[1]
[11]
[10]
[5]
[7]
[8]
[9]
[6]
29317749515
[1] LED displays
[2] Plug connector
[3] Potentiometer f2 (underneath the screw plug)
[4] Potentiometer f1 (underneath the screw plug)
[5] Screws for PE connection
[6] Mounting lug
[7] Cable glands M16
[8] Cable glands M25
[9] Nameplate
[10] Connection box
[11] Electronics cover (inverter)
29129451/EN – 12/2019
