6.13 Configuring the drive behavior at standstill (FCB02, FCB13, FCB14)
The parameter Behavior at standstill defines the drive behavior in case the drive en-
able is revoked and the motor is at standstill (path: Functions > Drive functions >
FCB02 Stop default). This parameter is effective when the function blocks FCB02,
FCB13 and FCB14 are active.
The following table lists the drive behavior after motor standstill:
Index Parameters Setting Behavior at motor standstill
Brake/
DynaStop
®
Motoring
position hold
control
Effect on the
the motor shaft
8563.1 Behavior at standstill
(Path: Functions >
Drive functions >
FCB02 Stop default)
Drive energized (brake
released / DynaStop
®
deactivated)
Brake re-
leased
Position hold
control
active
The motor shaft is
regulated to rota-
tional speed = "0"
by the motor.
DynaStop
®
is deactiva-
ted
Drive not energized
(brake applied /
DynaStop
®
activated)
Brake
applied
Motor de-ener-
gized
Motor shaft is held
by brake.
DynaStop
®
is activated
The motion of the
motor shaft is re-
tarded by
DynaStop
®
.
Drive not energized
(without brake/
DynaStop
®
)
Brake re-
leased
Motor de-ener-
gized
The motor shaft
can rotate freely.
DynaStop
®
is deactiva-
ted
