6
Startup
Detailed motor selection table for startup via DIP switch S3
Operating Instructions – MOVIMOT
®
flexible
149
6.6 Detailed motor selection table for startup via DIP switch S3
The following detailed motor selection tables show how to perform startup via DIP
switch S3 on the standard memory module (part no. 28242882).
6.6.1 DR2S.. motor series, 4-pole
DR2S.. motor series, 4-pole
230/400V, 50Hz 266/460V, 60Hz Wide-range voltage, 50/60Hz
DIP switch S3 DIP switch S3 DIP switch S3
S3/7 S3/8 S3/9 S3/10 S3/7 S3/8 S3/9 S3/10 S3/7 S3/8 S3/9 S3/10
1 1 0 0 0 0 1 0 1 0 1 0
Motor protection
Temperature sensor DIP switch S3
S3/5 S3/6
No temperature sensor 0 0
PK (PT1000) 1 0
TF 0 1
TH 1 1
The following table shows the settings of the DIP switch S3 depending on the motor
and the nominal output current of the inverter.
Motor Electronics cover DIP switch S3
Motor type Brake Type des-
ignation
Nominal out-
put current
Connec-
tion type
Motor assignment in rela-
tion to the inverter power
Type/nom-
inal voltage
S3/1 S3/2 S3/3 S3/4 Motor power
DR2S63M4
0020 2.0A
W 0 0 1 2 stages smaller
m 1 1 0 1 stage smaller
BE03/230V 0
0025 2.5A
W 0 1 1 3 stages smaller
m 1 0 1 2 stages smaller
0032 3.2A
W 0
m 1 1 1 3 stages smaller
BE03/230V 1
0040 4.0A
W 0
m 1
0055 5.5A
W 0
m 1
29129451/EN – 12/2019
