Device structure
Example nameplate and type designation of connection unit
Operating Instructions – MOVIMOT
®
flexible
28
3.9 Example nameplate and type designation of connection unit
3.9.1 Nameplate
The following figure gives an example of a nameplate of the connection unit. For the
structure of the type designation, refer to chapter "Type designation of the connection
unit".
3.9.2 Type designation of connection unit
The following table shows the type designation of the connection unit:
CU product family
CU = Connection unit
I Hardware design
I = for MOVIMOT
®
flexible MMF1.
C = for MOVIMOT
®
flexible MMF3.
1 Flange dimensions for relevant cover size
1 = Suitable for electronics cover size1 (with/without cooling fins)
H Fieldbus connection configuration
S = Standard
H = Hybrid
–
DFC Communication variant
DBC = Direct Binary Communication
DAC = Direct AS‑Interface Communication
DFC = Direct Fieldbus Communication
DSI = Direct System bus Installation
–
5 Connection voltage
5 = AC500V
D EMC variant
D = EMC filter with limit value category C3 (EN61800-3)
3 Connection type
3 = 3-phase
–
C Version
/
CO Option
DI = Digital Interface (MOVILINK
®
DDI)
CO = Digital interface (MOVILINK
®
DDI) via coaxial element
DSP = DynaStop
®
electrodynamic deceleration option
29129451/EN – 12/2019
