10.6 Motor/inverter assignments
The following motor/inverter assignments are valid for MOVIMOT
®
flexible.
10.6.1 Technical data DR.. motors
Key
P
N
Rated power
M
N
Rated torque
n
N
Rated speed
I
N
Rated current
cosφ Power factor
IE Short for "International Efficiency" (international efficiency class IE1 –
IE4)
η
50%
Efficiency at 50% of the rated power
η
75%
Efficiency at 75% of the rated power
η
100%
Efficiency at 100% of the rated power
I
A
/I
N
Starting current ratio
M
A
/M
N
Starting torque ratio
M
H
/M
N
Ramp-up torque ratio
M
K
/M
N
Breakdown torque ratio
m Mass of the motor
J
Mot
Mass moment of inertia of the motor
BE.. Brake used
Z
0
BG Switching frequency for operation with BG brake control
Z
0
BGE Switching frequency for operation with BGE brake control
M
B
Braking torque
m
B
Mass of the brakemotor
J
MOT_BE
Mass moment of inertia of the brakemotor
