Device structure
Example nameplate and type designation of the electronics
Operating Instructions – MOVIMOT
®
flexible
26
3.8 Example nameplate and type designation of the electronics
3.8.1 Nameplate
The following figure gives an example of a nameplate of the electronics cover. For the
structure of the type designation, refer to chapter "Type designation of the electronics
cover".
Eingang/Input
U= AC 3x380...500V
I= AC 1.8A
f= 50...60Hz
T= -25°C...+40°C ML 03
Status: 00 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00
U= 3x0V...Uinput
I= AC 2.0A
AC 6.0AImax=
f= 0...599Hz
Ausgang/Output
Type: DBC10A-0020-503-A-000-000
S0#: 01.7569637446.0001.19
D-76646 Bruchsal
Made in Germany
30508895371
3.8.2 Type designation of the electronics cover
The following table shows the type designation of the electronics cover:
DBC Product family
DBC = Electronics cover Direct Binary Communication
1 Communication type
1 = Binary
0 Port configuration
0 = M12 plug connector on electronics cover (standard)
A Communication version
–
0020 Nominal output current of the electronics cover
0020 = 2.0A
0025 = 2.5A
0032 = 3.2A
0040 = 4.0A
0055 = 5.5A
–
5 Connection voltage
5 = AC500V
0 Power section design EMC
0 = Basic interference suppression
1 = IT system design
3 Connection type
3 = 3-phase
–
