SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series User Manual

7
Operation
Function "Releasing the brake / deactivating DynaStop® with FCB01"
Operating Instructions – MOVIMOT
®
flexible
182
7.6 Function "Releasing the brake / deactivating DynaStop
®
with FCB01"
Function
"Releasing
the brake /
deactivatin
g
DynaStop®
with
FCB01"
7.6.1 Information
INFORMATION
For information on how to disable the DynaStop
®
function for startup and assembly
purposes, refer to chapter "Startup".
7.6.2 Activating the function
WARNING
Risk from falling loads.
This can result in severe or fatal injuries.
• Do not use the function "Releasing the brake / deactivating DynaStop
®
with
FCB01" for hoist applications and applications with potentially falling loads.
• Inhibit the function via the following steps:
– Deactivate the function of the DIP switch S1/2 using the parameter Deactiva-
tion = "1" (path: Functions > Inputs/outputs > Basic device > DIP switch func-
tions > Releasing the brake / deactivating DynaStop
®
with FCB01 – enable)
– Inhibit the functions using the parameter Releasing the brake / deactivating
DynaStop
®
with FCB01 – enable = "0" (path: Functions > Drive functions >
FCB01Output stage inhibit).
In case the output stage is inhibited, you can deactivate the DynaStop
®
function/re-
lease the brake by a control signal (digital input or process data bit) using the function
"Releasing the brake / deactivating DynaStop
®
with FCB01". For example, this allows
to move loads freely using a horizontal conveyor.
Now make the following settings:
1. Enabling the function:
• Via DIP switch S1/2
Set the DIP switch S1/2 "Releasing the brake / deactivating DynaStop
®
with
FCB01 – enable" = ON.
• Via parameter settings
Deactivate the DIP switch S1/2 by setting the parameter Deactivation = "1".
(Path: Functions > Inputs/outputs > Basic device > DIP switch functions > Re-
leasing the brake / deactivating DynaStop
®
with FCB01 – enable)
Enable the function "Releasing the brake / deactivating DynaStop
®
with FCB01
– enable" by setting the parameter Releasing the brake / deactivating
DynaStop
®
with FCB01 – enable to "1" [1].
(Path: Functions > Drive functions > FCB01 Output stage inhibit)
29129451/EN – 12/2019
