6
Startup
DIP switch
Operating Instructions – MOVIMOT
®
flexible
142
6.5 DIP switch
6.5.1 Overview
NOTICE
Damage to the DIP switches caused by unsuitable tools.
Possible damage to property.
• To set the DIP switches, use only suitable tools, such as a slotted screwdriver
with a blade width of no more than 3mm.
• The force used for setting the DIP switches must not exceed 5N.
The following figure shows the DIP switches of the device:
S1 1 2 3 4 1 2 3 4 S2
4 S2
t1
On
Off
f1 f2
4321
ON
4321
ON
3 5 64 7
ON
1 2 3 4
S1
ON
1 2 3 4
S2
ON
1
S3
2 3 4 5 6 7 8 9 10
9007228267677579
DIP switch S1
The following table shows the functions of DIP switch S1:
DIP switch S1
1 2 3 4
Meaning Direction of
rotation
reversal
Releasing the
brake /
deactivating
DynaStop
®
with
FCB01 – en-
able
Speed monito-
ring
deactivation
Reserved
ON On On Speed
monitoring
Off
On
OFF Off
1)
Off
1)
Speed
monitoring
On
1)
Off
1)
1) The factory settings are shown in boldface.
29129451/EN – 12/2019
