7
Operation
Mechanical brake in connection with STO
Operating Instructions – MOVIMOT
®
flexible
189
7.8 Mechanical brake in connection with STO
7.8.1 Using the mechanical brake in connection with the STO function
The following table shows the behavior of the drive depending on the parameter set-
tings:
Index Parameters Setting Meaning
8563.1 Behavior at standstill
(Path: Functions >
Drive functions >
FCB02 Stop default)
Drive energized
(brake released
/ DynaStop
®
deacti-
vated)
If the enable signals are revoked, the drive deceler-
ates according to the active deceleration setpoint.
When the speed is "0", the brake remains released.
Motor position hold control is active.
Drive not energized
(brake applied /
DynaStop
®
activa-
ted)
If the enable signals are revoked, the drive deceler-
ates according to the active deceleration setpoint.
When the speed is "0", the brake is applied. The mo-
tor is de-energized.
8501.3 Apply brake/activate
DynaStop
®
in STO
state
(Path: Functions >
Drive functions >
FCB01 Output stage
inhibit > Brake/
DynaStop
®
)
0 (no) The brake state remains unchanged when STO is
activated.
1 (yes) The brake is activated (not safety-related) when STO
is activated.
Recommended setting
29129451/EN – 12/2019
