Siemens SED2 Commissioning Guide

22 / 100
Siemens Commissioning Guide CM1G5192en
Building Technologies 5 Electrical installation 29.07.2010
5.2.4 Power and motor terminals: Frame sizes A…F
Terminal layout:
Frame size A
(Ground)
PE
(Ground)
L1
L2
L3
DC+ DC-
UVW
5192Z05
DC
R+
B-
Terminal layout:
Frame sizes B and C
UV WDC- DC+
B+
DC
R+
B -
L3
L2
L1
PE
5192Z06
Terminal layout:
Frame sizes D and E
L1 L2 L3 DC- DC+
B+
DC
R+
B- U V W
PE
5192Z07
