Siemens SED2 Commissioning Guide

64 / 100
Siemens Commissioning Guide CM1G5192en
Building Technologies 10 Parameterization 29.07.2010
10 Parameterization
10.1 Block diagram with parameter overview
PE
U
V
W
PE
PE
AOUT1
D / A
Motor
PTC
BOP (Standard)
M
CPU
AOUT2
D / A
LG-
Ni1000
DIN 1
DIN 2
DIN 3
DIN 4
DIN 5
DIN 6
AOP (optional)
3
LG-
Ni1000
AIN1
AIN2
A / D
A / D
DC+
DC-
Analog inputs 1+2
P0756 - P0762
Digital input
P0700
Command source
P0701 - P0706
(P0705 counter)
r0722 - P0725
(NPN - PNP)
Analog inputs 1+2
configured as
digital inputs
P0707 - P0708
PTC
P0601
PID
P2200
P2201 - P2231
P2240 - P2254
P2253 - P2305
P2264 - r2272
Enable PID
Fixed setpoint
PID setpoint
Standard setpoint
PID feedback
Analog output
P0771 - P0781
VSD features
P1270 Enable essential mode
P1210 - P1212 automatic restart
Communication
P2000 - r2091
VSD parameters
P0003
P0010
r0026
r0039 - P0040
P0100
r0206 - r0209
P1000 - P1028
P1080 - P1110
DOUT
P0731 - P0732
r0747 - P0748
MMI (BOP)
r0000
P0005
r0019 - r0039
AOP optional
See AOP operating
instructions
