Siemens Commissioning Guide CM1G5192en
Building Technologies 7 Applications 29.07.2010
7.4.1 Parameter changes
Start with quick commissioning according to application 1
Par. no. Value Parameter function Function selection
P0003 3 User access level Expert access
P0701(0) 16 Fixed setpoint (direct selection + ON)
P0702(0) 29
Function of digital input 2 in “Auto”
mode
In the event of external alarm, fan will be stopped
P0702(1) 29
Function of digital input 2 in “Hand”
mode
In the event of external alarm, fan will be stopped
P0756(1) 1 Defines analog input 2 DC 0...10 V (default)
P0757(1) 0 Scaling of analog input 2: x1 (Default)
P0758(1) 0 Scaling of analog input 2: y1 (Default)
P0759(1) 10 Scaling of analog input 2: x2 (Default)
P0760(1) 100 Scaling of analog input 2: y2 (Default)
P2201 50% Setpoint of pressure control 50% of 500 Pa = one setpoint 250 Pa
P2253(0) 2224 Setpoint source Internal setpoint
P2306 1 PID acting direction Indirect
P2200(0) 1 Enable PID controller PID controller enabled
P2280 0.5 PID proportional gain
P2285 60 s PID integral action time
r2262 Current setpoint
r2272 Current feedback
