36 / 100
Siemens Commissioning Guide CM1G5192en
Building Technologies 6 Commissioning 29.07.2010
6.5 Quick commissioning
Quick commissioning allows the user to get started in the shortest possible time.
The grayed out parameters can be left as the VSD will calculate a value or use the factory default values. We
suggest to check these values before the VSD is put into service.
Parameter Default Set to Function
P0010
1 = Quick
commissioning
0
1
Start quick commissioning
P0010 must always be set back to “0” before operating the motor.
However if P3900 is set = 1 after commissioning, this is carried out
automatically
P0100
0 = kW / 50 Hz
1 = hp / 60 Hz
2 = kW / 60 Hz
0
0
For use in Europe / N. America
For setting 0 and 1, use DIP switch 2
For setting 2, use P0100
P0304
10 – 2,000 V
230
Rating
plate
Rated motor voltage
Nominal motor voltage (V) from rating plate
P0305
0 ... 10,000 A/nom
3.25
Rating
plate
Rated motor current
Nominal motor current (A) from rating plate
P0307
0 – 2000 kW
0.75
Rating
plate
Rated motor power
Nominal motor power (kW) from rating plate. If P0100 = 1, values will
be in hp
P0308
0 -1.000
0
Rating
plate
Rated motor power factor
Nominal cosPhi from rating plate
P0309
0 – 99.9
0
Rating
plate
Rated motor efficiency
Nominal motor efficiency from rating plate
P0310
12 - 650 Hz
50.00
Rating
plate
Rated motor frequency
Nominal motor frequency from rating plate
P0311
0 – 40,000 rpm
0
Rating
plate
Rated motor speed
Nominal motor speed from rating plate
P0700[2]
Index 0: Auto
Index I : Hand
2
1
2
1
Selection of command source (on / off )
1 = BOP
2 = Terminal / digital inputs
P1000[2]
Index 0: Auto
Index I : Hand
2
1
2
1
Selection of frequency setpoint
1 = BOP Basic Operator Panel
2 = Analog setpoint
P1080
0 – 150 Hz
10.00
Site
setting
Min. motor frequency
Sets the minimum motor frequency at which the motor will run,
irrespective of the frequency setpoint. The value set here is valid for
both clockwise and counterclockwise rotation
P1082
0 - 150 Hz
50.00
Site
setting
Max. motor frequency
Sets the maximum motor frequency at which the motor will run,
irrespective of frequency setpoint. The value set here is valid for both
clockwise and counterclockwise rotation (do not normally set this
higher than 50 Hz unless the motor can be used at higher frequencies)
P1120
0 - 650 s
10
Site
setting
Ramp-up time
Time taken for the motor to accelerate from standstill up to maximum
motor frequency
P1121
0 - 650 s
30
Site
setting
Ramp-down time
Time taken for the motor to decelerate from maximum motor frequency
down to standstill
P3900
0 - 3
0
1
P3900 end quick commissioning
0 = End without motor calculation or factory reset
1 = End with motor calculation and factory reset (recommended)
2 = End with motor calculation and with I/O reset
3 = End with motor calculation but without I/O reset
