6.9 Copying SED2 parameters
Caution!
After the copy process, quick commissioning is mandatory, which must be
concluded with parameter P3900=3.
If parameter sets are transferred or copied, motor data in the respective VSD must
checked and compared with those of the connected motor.
If this is not observed, the connected motor will not operate troublefree and, in
extreme cases, the SED2 will be damaged, the reason being the motor parameters
(e.g. stator resistance) which are also copied in this process.
Up- and download of a parameter set can be effected in 2 different ways:
• With an AOP
• With the PC EasyComm software
6.9.1 Procedure
Uploading parameter sets
AOP: Refer to Operating Instructions (CM1B5192en)
EasyComm: Upload VSD parameter set to PC / laptop
Downloading parameter sets
AOP: Refer to Operating Instructions
EasyComm: Download the parameter set from the PC / laptop to another VSD
Entry of motor data
Quick commissioning
Par. no. Value Parameter function Function selection
P0010 1 Commissioning parameter filter Quick commissioning
P0304 V Rated motor voltage According to motor’s rating plate
P0305 A Rated motor current According to motor’s rating plate
P0307 kW Rated motor power According to motor’s rating plate
P0310 Hz Rated motor frequency According to motor’s rating plate
P0311 1/min Rated motor speed According to motor’s rating plate
P1080 ≥ 10.00 Min. frequency
P1082 Hz Max. frequency
P1120 20 s Ramp-up time
P1121 30 s Ramp-down time
P3900 3 End of quick commissioning Quick commissioning only for motor data
Check motor data
Caution!
The motor data specified for use by the SED2 must accord with those of the
connected motor! In particular, the ramp-up time (P1120) and ramp-down time
(P1121) must be matched to the motor in use.
When using the PID controller, the parameters of PID proportional gain (P2280),
PID integral action time (P2285) and PID derivative action time (P2274) must be
matched to the controlled system!
