Siemens SIPROCESS GA700 Compact Operating Instructions

Table 7-14 OXYMAT 7: Gas connections
Gas connections
With pipes Connecting socket for pipe with ∅ 6mm
Table 7-15 OXYMAT 7: Parts in contact with sample gases
Materials of parts in contact with
sample gases
OXYMAT 7 OXYMAT 7 high-temperature
1)
Sample chamber Stainless steel:
• Plates: Material No. 1.4571
• Screw-in glands: No. 1.4571
Hastelloy:
• Plates: Material No. 2.4602
• Screw-in glands: Material No. 2.4819
Stainless steel:
• Plates: Material No. 1.4571
Hastelloy:
• Plates: Material No. 2.4602
Gas path

Stainless steel:
• Pipes: Material No. 1.4404
• Gas connections: Material No. 1.4571
Hastelloy:
• Pipes: Material No. 2.4602
• Gas connections: Material No. 2.4819
Stainless steel:
• Gas connections: Material No. 1.4571
Hastelloy:
• Gas connections: Material No. 2.4602
Sealing material FKM (e.g. Viton) or FFKM (Kalrez6375)
1)
The high-temperature version of the analyzer module is not intended for installation in the rack unit.
Table 7-16 OXYMAT 7: The maximum release amount of sample gas
Analyzer module Max. release amount
OXYMAT 7 200 μl/min
7.1.4 ULTRAMAT 7
Table 7-17 ULTRAMAT 7: General technical data
General ULTRAMAT 7 ULTRAMAT 7 high-temperature
1)
Information on the smallest span See module nameplate
Max. power consumption ≤ 30W ≤ 120W
Weight (only module) Max. 5.2kg Max. 7.2kg
Max. EMC error during operation with one
and/or two OXYMAT 7/ ULTRAMAT 7 units
1.0% according to EN 61326-1
1)
The high-temperature version of the analyzer module is not intended for installation in the rack-mounted device.
Technical data
7.1General technical speci󹪝cations
SIPROCESS GA700 rack and wall mounted devices
94 Compact Operating Instructions, 06/2023, A5E35134047-AB
