Table 7-31 CALOMAT 7: The maximum release amount of sample gas
Analyzer module Max. release amount
CALOMAT 7 400 μl/min
7.2 Operation in hazardous areas
The following tables show the data relevant to explosion protection. If the values speci󹪝ed below
deviate from the values of the general technical speci󹪝cations, the speci󹪝cations listed in this
section apply.
Compare the speci󹪝cations in this section with the speci󹪝cations in the section"General
technical speci󹪝cations (Page87)".
Note
Validity of technical speci󹪝cations
The technical speci󹪝cations for explosion-proof devices are only valid in combination with the
type test certi󹪝cate. The technical speci󹪝cations listed below are regarded as general. If these
values deviate from those of the type test certi󹪝cate, the values of the type test certi󹪝cate apply.
Table 7-32 Location of use
Location of use
Danger zone Zones 1, 2, 22
Ambient temperature
Rack-mounted device /
Wall-mounted device
OXYMAT 7 / CALOMAT 7 0...50°C (32...122°F) (reduces if used in combination with U7)
ULTRAMAT 7 5°C ... +45°C (41...+133°F)
Moisture No cooling below dew point during storage and operation
Permissible operating height 2000 m above sea level
1)
1)
Also above, after individual check. Contact Siemens partner for more information, if necessary.
Table 7-33 Electrical connection data for wall-mounted and rack-mounted device
Electric connection data All analyzers, all types of protection, if not speci󹪝ed otherwise
Power supply 85 ... 264 V AC, 47...63Hz
Analog outputs 0/2/4...20mA, potential-free, load: 750 Ω
Galvanically isolated and fuse protected to < 20 W
Analog inputs Limiting of the operating power to < 20 W (10 V ± 50 mA)
Digital outputs / relay contacts

24V AC/DC; 1.7 A
Are designed for 24V, galvanically isolated from the electronics and insulated by air and
creepage distances 24V.
Digital inputs Limiting of the operating power to < 20 W (33 V ± 15 mA)
Ethernet interface RJ 45
Technical data
7.2Operation in hazardous areas
SIPROCESS GA700 rack and wall mounted devices
98 Compact Operating Instructions, 06/2023, A5E35134047-AB
