4-2. SERVICE Menu
This unit is provided with the SERVICE menu useful for maintenance.
For how to display the SERVICE menu, refer to “4-1-2. Starting and Exiting the SERVICE Menu”.
4-2-1. SERVICE Menu List
Screen display
CONTENTS ?S00 TOP
01 <SOFTWARE PACKAGE>
02 <PLD PACKAGE>
03 <RESET>
04 <SERIAL NUMBER>
05 <ANALOG ADJUST>
06 <POWER UNIT>
07 <MODE>
08 <TEMPERATURE>
Description
Menu Page No. Menu Page Name Remarks
S01 SOFTWARE PACKAGE Displaying and updating software version
S02 PLD PACKAGE Displaying and updating PLD version
S03 RESET Initializing setting values
S04 SERIAL NUMBER Displaying serial number
S05 ANALOG ADJUST Fine-adjusting PROMPTER input level and 27 MHz VCO flee-run
S06 POWER UNIT Displaying power unit status
S07 MODE Operation mode setting for connection terminal
S08 TEMPERTURE Displaying temperature at each point
4-2-2. Description of SERVICE Menu
Tip
The display screen appearing in this section shows the indication example.
HDCU3500/HDCU5500
4-3
