1-7. PLD
This unit uses the PLD (Programmable Logic Device) that supports USB drive to write and rewrite the internal data.
If the part listed below needs to be replaced or to be upgraded, contact your local Sony Sales Office/Service Center.
Note
The part number of PLD (or ROM for PLD) in which data is not written yet, is shown in “Spare Parts”.
Therefore, if part replacement is required, write the data by the following procedure.
In the case of the PLD type that runs on the program stored in external ROM, data needs not to be written only by
replacing the part if the specific PLD only is defective.
Tip
The USB connector for connection to a USB drive is located to the right of the CALL button on the front panel. Detach
the USB connector lid to connect the USB drive.
1-7-1. Corresponding PLDs
Board name Ref. No. File name
SY-467 IC1200 hdcu5000_sy.pkg
TX-167 IC1501 hdcu5000_tx1_high.pkg
hdcu5000_tx1_ultra.pkg
IC601 hdcu5000_tx2.pkg
VIF-75 IC1700 hdcu5000_vif.pkg
NET-37 IC001 hdcu5000_net1.pkg (HKCU-SFP50 is installed)
IC001 hdcu5000_net2.pkg (HKCU-SFP50 is installed)
ENC-185 IC001 hdcu5000_enc1_xavc.pkg (HKCU-REC55 is installed)
MDC-23 IC401 hdcu5000_enc2_rec55.pkg (HKCU-REC55 is installed)
1-7-2. Upgrading PLD Data
Equipment Required
• USB drive (commercially available)
Tip
For recommended USB drive, contact your local Sony Sales Office/Service Center.
Preparation
Copy the PLD update data to the USB drive using the following procedure.
Note
For how to obtain the data files for update, contact your local Sony Sales Office/Service Center.
1. Create the following directory in the USB drive.
\MSSONY\PRO\CAMERA\HDCU5000
2. Copy the data files for PLD update to be updated to the directory created.
HDCU3500/HDCU5500
1-17
