2 Set the [Key Active] button to the on state and set the
following parameters.
a) No filter is applied when set to “1”. The larger the value, the
stronger the filtering applied.
Adjusting the window
1 Open the Home > M/E-1 > Key1 > Type > Chroma
Adjust menu (11101.12).
2 Set the [Window] button to the on state and set the
following parameters.
Adjusting the Y balance
1 Open the Home > M/E-1 > Key1 > Type > Chroma
Adjust menu (11101.12).
2 Set the [Y Balance] button to the on state and set the
following parameters.
Adjusting the shadow
When the system signal format is 2160P, the shadow
function cannot be set.
1 Open the Home > M/E-1 > Key1 > Type > Chroma
Adjust menu (11101.12).
2 Set the [Shadow] button to the on state and set the
following parameters.
Adjusting color cancel
1 Open the Home > M/E-1 > Key1 > Type > Chroma
Adjust menu (11101.12).
2 Set the [Color Cancel] button in the [Color Cancel]
group to the on state and set the following parameters.
a) No filter is applied when set to “1”. The larger the value, the
stronger the filtering applied.
To adjust the color cancel key
Set the key signal for color cancel.
1 Set the [Cancel Key] button in the [Color Cancel]
group to the on state and set the following parameters.
2 Set the [Key Position] button in the [Color Cancel]
group to the on state and set the following parameters.
Adjust the position of the color cancel key.
3 Set the [Window] button in the [Color Cancel] group
to the on state and set the following parameters.
Adjust the detection range of the color cancel key.
No. Parameter Adjustment
1 Clip Reference level for key signal
ge
neration
2 Gain Key gain
3 Hue Key hue
4 Density Key density
5 Filter Filter (1 to 9)
a)
No. Parameter Adjustment
1 Crop Vertex crop level
2 Angle Opening angle
No. Parameter Adjustment
1 Clip Reference level for key signal
ge
neration
2 Gain Key gain
3 Luminance Key luminance
Note
No. Parameter Adjustment
1 Luminance Key luminance
2 Gain Key gain
3 Density Key density
4 Soft Softness of shadow
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
5 Filter Filter (1 to 9)
a)
No. Parameter Adjustment
1 Clip Reference level for key signal
ge
neration
2 Gain Key gain
No. Parameter Adjustment
1 H Phase Simultaneous adjustment of
po
sition of left and right
edges
2 Left Position of left edge
3 Right Position of right edge
No. Parameter Adjustment
1 Crop Vertex crop level
2 Angle Opening angle
