428
To set action preferences
You can set the timing, pulse width, and register to recall
by
the action for a GPI output.
1
Select the target GPI output to set.
2
Press the [Action Details] button for [Reg/Timing/
Pulse Width].
The [Action Details] window appears.
3
Set the action preferences.
When a register recall action is selected
Press the [Register No.] button and enter a register
n
umber in the numeric keypad window.
When [Rising Edge]/[Falling Edge]/[Any Edge]
trig
ger type is selected
Press the [Timing] button and select a timing (Field1,
F
ield2, Any) from the pull-down list.
When [Rising Edge]/[Falling Edge] trigger type is
sel
ected
Press the [Pulse Width] button and enter a pulse width
(
fields) in the numeric keypad window.
4
Press [OK].
Trigger type and actions list
1)
When the trigger type is other than [Status]:
P/P Keyx SS Recall, M/E-x Keyx SS Recall, No Action
When the trigger type is [Status]:
P/P Keyx SS Recall, M/E-x Keyx SS Recall, No Action
P/P Keyx On, M/E-x Keyx On
Error Make, Error Break, Keep Make, Keep Break,
Devi
ce Recording
1) “M/E-x” is M/E-1 to M/E-5
“Keyx” is Key1 to Key8
Testing trigger output
You can output a test trigger from a GPI output port.
A trigger is not output when the trigger type is [Status].
1
Open the Home > Setup > External Device > GPI
Output Assign menu (19105.41).
2
Select the target GPI output to set.
3
Press the [Test Fire] button.
Setting the Connection
Port of External Devices
Setting the Connection Port
You can set the protocol (device type) of a device
connected to a serial port or network port, and set the
control panel to use for device operation.
The maximum number of ports that can be used,
in
cluding serial ports and network ports, is 40.
A serial port can be used when an MKS-X1700 Legacy
In
terface Board (option) is installed.
There are eight serial ports in each box, and serial port
numb
ers (1 to 40) are assigned sequentially starting
with a logical box ID of 1.
The network port uses the network connected to the box
wit
h a logical box ID of 1.
Control of P-Bus compatible devices, AMP compatible
devi
ces, and TCP/IP connected devices is supported on
network ports.
Control of AMP compatible devices is not supported on
seri
al ports.
1
Open the Home > Setup > External Device > Serial/
Net Port Assign menu (19105.51).
2
Select the target port to set.
3
Press the [Assign Type] button for [Serial Tally/
Device Type].
The [Assign Type] window appears.
4
Set the button for the target device type to the on
state.
You can select the following device types.
P-Bus: P-B
us compatible device
VTR: VT
R (Sony 9-pin VTR protocol)
DDR VDCP:
Disk recorder (video disk
communications protocol)
DDR Odetics: Disk
recorder (Odetics protocol)
AMP: AMP co
mpatible device
General TCP/IP: T
CP/IP connected devices
(general-purpose)
Serial Tally 1: Se
rial tally port 1
Serial Tally 2: Se
rial tally port 2
No Assign: No a
ssignment
Note
Notes
