481
6
Press the [Prefix Length] button and enter a prefix
length in the numeric keypad window.
When multiple LAN ports are selected, the same
pr
efix length is set.
7
Press the [Gateway] button and enter an address using
the keyboard.
When multiple LAN ports are selected, the same
g
ateway is set.
8
Press the [Apply] button.
To return to the previous setting
Press the [Clear] button, check the message, then
p
ress [OK].
9
Check the message, then press [OK].
To identify the box corresponding to a LAN port
Select the target LAN port and press the [Send Beacon]
bu
tton to cause the front panel LED bars on the box
corresponding to the selected LAN port to flash for
5 seconds.
Configuring Control Panel Bank
Network Settings
You can configure the network settings of control panel
banks that are not configured in a control panel.
For details about configuring the network settings of a
con
trol panel not assigned to a switcher in an island, see
“Configuring Control Panel Network Settings”
(page 467).
For details about configuring the network settings of a
c
ontrol panel assigned to a switcher in an island, see
“Configuring Control Panel Network Settings”
(page 474).
1
Open the MLS Manager Home > System > Off-Island
> Panel Network menu (60219.03).
2
Press the [Detect/Refresh] button.
Control panel banks that are not configured in a
co
ntrol panel and are on the same network as MLS
Manager are detected.
If no control panel bank connections are detected, the
icon is displayed. Press the [Detect/Refresh]
button to run control panel bank detection again.
3
Select the target control panel bank to set.
Place a check mark for the target control panel bank
t
o set (multiple selection supported).
To select and set all control panel banks, place a
chec
k mark in the Select All checkbox.
4
Press the [Edit Panel Bank] button.
A setup window for the selected control panel bank
app
ears.
5
Press the [Hostname] button and enter a host name
(up to 63 characters) using the keyboard.
Cannot be configured when multiple control panel
ban
ks are selected.
6
Press the [Address] button for [IPv4] and enter an
address using the keyboard.
When multiple control panel banks are selected,
con
secutively numbered IP addresses are set.
7
Press the [Prefix Length] button for [IPv4] and enter
a prefix length in the numeric keypad window.
When multiple control panel banks are selected, the
sa
me prefix length is set for all the control panel
banks.
8
Press [OK].
9
Press the [Apply] button.
10
Check the message, then press [OK].
To identify a control panel bank
Press the [Send Beacon] button to cause the buttons in the
sele
cted control panel bank to flash for 5 seconds.
Note
Note
Note
Note
Note
Note
