208
3
Press the [Sepia Color] button and set the sepia color
using the following parameters.
Setting Mono
Enabling Mono disables Sepia if it is set.
1
Open the Home > DME > Channel1 > Video Modify
> Color Modify menu (15101.32).
2
Set the [Mono] button to the on state.
Setting a Mosaic
1
Open the Home > DME > Channel1 > Video Modify
> Mosaic menu (15101.33).
2
Set the [Mosaic] button to the on state and set the
following parameters.
Setting a Mask
You can mask out part of a Defocus, Sepia, Mono, or
Mosaic effect.
Separate masks can be set for group 1 effects (Sepia,
Mo
no, Mosaic) and group 2 effects (Defocus).
If a border has been set and then masks are enabled on
bot
h group 1 effects and group 2 effects, the Border effect
will also be masked.
1
Open the Home > DME > Channel1 > Video Modify
> Mask menu (15101.34).
2
In [Effect Group], set the [Mask] switch for the target
effect to the on state.
Group 1: S
epia, Mono, and Mosaic effects
Group 2: Defo
cus effect
3
Press the [Position/Size] button and set the mask
pattern using the following parameters.
The mask patterns are the same as wipe pattern
numb
ers 21, 24, and 304.
To set the aspect ratio of a mask pattern
(A
spect)
Press the [Aspect] button and set the following parameter.
To rotate a mask pattern
In the [Rotation] group, select a rotation type.
Angle: Incl
ine a pattern at a fixed angle.
Speed: Rot
ate a pattern at a fixed speed.
When the [Angle] button is selected, set the following
p
arameter.
2 Mix C Chrominance signal mix
amount
3 Mix All Simultaneous adjustment of
l
uminance signal and
chrominance signal mix
amounts
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Hue Hue
Note
No. Parameter Adjustment
1 Size Tile size
2 Aspect Tile aspect ratio
• Negative values expand
ve
rtically.
• Positive values expand
hori
zontally.
No. Parameter Adjustment
Note
No. Parameter Adjustment
1 H Horizontal position
2 V Vertical position
3 Size Size
4 Soft Softness
5 Pattern Pattern number (21, 24, 304)
Note
No. Parameter Adjustment
1 Aspect Aspect ratio
• Negative values expand
ve
rtically.
• Positive values expand
ho
rizontally.
No. Parameter Adjustment
1 Angle Inclination angle of pattern
• A value of –1.00 corresponds to
a rotat
ion of one turn
counterclockwise.
• A value of +1.00 corresponds to
a r
otation of one turn clockwise.
• A value of 0.00 corresponds to
no rotation.
To Next Page
